HART (Highway Addressable Remote Transducer)

HART (Highway Addressable Remote Transducer) is a widely-used industrial automation protocol that combines analog and digital communication over the same pair of wires. It is particularly notable for its ability to operate over legacy 4–20 mA analog instrumentation current loops, making it a versatile and efficient solution for both new and existing systems.

Key Features:

1. Hybrid Communication:

   • HART uses a hybrid analog+digital communication method, allowing it to transmit both analog signals (4–20 mA) and digital data simultaneously. This dual-communication capability ensures that the analog signal remains unaffected by the digital communication, providing a robust and reliable data transfer mechanism.

2. Operational Modes:

   • Point-to-Point Mode: In this mode, digital signals are overlaid on the 4–20 mA loop current. Both the analog and digital signals are valid, and the polling address of the instrument is set to "0". This mode is typically used for one-to-one communication between a controller and a measuring instrument.

   • Multi-Drop Mode: This mode allows multiple instruments to be connected on a single pair of wires, with the analog loop current fixed at 4 mA. Each instrument has a unique address, and all process values are transmitted digitally. This configuration supports up to 15 field devices.

3. Burst Communication Mode:

   • An optional mode where a single slave device can continuously broadcast a standard HART reply message. This mode enables higher update rates and is usually restricted to point-to-point configurations.

4. Compatibility and Integration:

   • HART is designed to be compatible with existing 4–20 mA wiring, making it easy to integrate into legacy systems. It supports a wide range of intelligent field devices, including sensors, actuators, and controllers. The protocol is maintained by the FieldComm Group, ensuring its compatibility and interoperability with various automation platforms.

5. Applications:

   • HART is used in a variety of industrial applications, from small automation tasks to complex process control systems. Its ability to provide detailed diagnostic information and support remote configuration makes it a valuable tool for improving operational efficiency and reducing maintenance costs.

6. Protocol Structure:

   • The HART protocol is based on the Bell 202 standard and uses Frequency Shift Keying (FSK) to superimpose digital communication signals on the analog signal. The digital signal operates at 1200 bps, providing 2–3 data updates per second without interrupting the 4–20 mA signal.

7. Global Standard:

   • With over 30 million devices installed worldwide, HART is considered the most popular protocol in industrial automation. Its open standard nature and extensive support from major automation vendors contribute to its widespread adoption.

Benefits:

• Enhanced Diagnostics: HART provides detailed diagnostic information, allowing for early detection of device and process issues.

• Remote Configuration: Devices can be configured and monitored remotely, reducing the need for field visits.

• Compatibility: Seamless integration with existing 4–20 mA systems, minimizing the need for infrastructure upgrades.

• Reliability: The protocol's robust design ensures reliable communication even in harsh industrial environments.

Conclusion:

HART (Highway Addressable Remote Transducer) is a critical protocol in industrial automation, offering a blend of analog and digital communication that enhances the capabilities of legacy systems. Its widespread adoption and robust feature set make it an essential tool for improving operational efficiency and reliability in various industrial applications.
